BREAK FREE FROM FIBER

PERFORMANCE, SCALABILITY, & FLEXIBILITY

NAVIGATOR

Microwave 6–42GHz

Up to 2.75Gbps in the single transceiver radio
Up to 5.5Gbps in the dual transceiver radio

APPLICATIONS

  • Fiber extension/replacement/backup
  • 3G/4G backhaul and seamless transition to 5G
  • Shared networks & Mobile fronthaul
  • WAN/LAN connectivity
  • Disaster recovery
  • Video surveillance

NAVIGATOR is a licensed microwave system supporting the 6-42GHz frequency bands, and offering performance and features far exceeding that of microwave radios manufactured using off-the-shelf chipsets. Built on the company’s proprietary custom ASICs, NAVIGATOR provides network operators with unprecedented flexibility to support multiple configurations and applications, optimize networks for the highest capacity and range, upgrade legacy networks, and speed up deployments, while minimizing both upfront investment costs and the ongoing costs to maintain and service networks.

FEATURES

  • Up to 1.5Gbps in a single channel per single transceiver radio for true fiber replacement capacity
  • Dual sub-carrier support to efficiently increase capacity without adding more equipment
  • QPSK to 4096QAM
  • Ultra-wide bandwidth operation to 160MHz ANSI and 112MHz ETSI
  • 1+0, 1+1 HSB, and 2+0 operation
  • Space Diversity and Frequency Diversity available
  • Built-in Advanced Digital Pre-Distortion to drive higher transmission performance
  • Customer-replaceable diplexers to ease operational logistics and improve system flexibility
  • Adaptable antenna interface option supports third party antennas to ease migration and upgrade
  • Header and payload compression to further increase capacity
  • 2 x 10GbE Ethernet interfaces (optional)
  • 2 x CPRI interfaces (optional)
  • SyncE and IEEE1588v2
  • AES256 encryption (optional)
  • No-touch Wi-Fi maintenance interface (optional)
  • Time based feature licensing available

Millimeter Wave

70-80GHz

Up to 9.7Gbps in up to 2000MHz bandwidth per radio

APPLICATIONS
The Flex4G-10000 system supports any application where fiber capacity is the primary requirement including:

  • Fiber extension/replacement/backup
  • 3G/4G backhaul and seamless transition to 5G
  • Shared networks
  • Mobile fronthaul
  • WAN/LAN connectivity
  • Disaster recovery
  • Video surveillance

The Flex4G-10000 is an E-band (70/80GHz) millimeter wave system that delivers up to 9.7Gbps capacity, 256 bit AES encryption for highest data security, and the highest system gain in the industry to ensure maximum throughput at the longest distances. The Flex4G-10000 offers mobile network operators a much lower cost alternative to fiber in macro/cell backhaul and fronthaul for Centralized Radio Access (C-RAN) networks, supporting up to CPRI Mode 7 (9830.4Mbps), while offering ISPs, enterprises, and government agencies a much lower cost alternative to fiber.

The all outdoor Flex4G-10000, which operates in the E-band range (71-86GHz) and is already shipping to customers, has been designed to alleviate the strain of backhaul connections by combining advanced radio and modem capabilities with carrier-grade 10G Ethernet, CPRI, and SONET/SDH features. The radio scales from QPSK to 256 QAM, and from 500 MHz to 2000 MHz, allowing the customer to select the optimal combination of range and throughput. The Flex4G-10000 is also easily and cost-effectively scalable to 10Gbps for BridgeWave customers who have installed Flex4G-UHA, Flex4G-3000, or Flex4G-5000 systems, because it is fully compatible with the antennas deployed with those systems.

FEATURES

  • 9.7 Gbps data rate per 1+0 radio
  • 1+0, 1+1 HSB, 2+0 configuration support
  • Adaptive Code Modulation from QPSK through 256QAM
  • 500, 1000, and 2000MHz bandwidth support
  • SONET/SDH & CPRI interfaces including support up to CPRI Mode 7 (9830.4Mbps) for C-RAN networks
  • Highest bit/Hz spectral efficiency at the longest link distances
  • Outstanding RF performance benefiting from highly integrated architecture
  • LDPC FEC providing threshold improvement over other FEC technologies
  • RF channel tuning in 250 MHz steps
  • Automatic Transmit Power Control
  • Zero-footprint ODU with low power consumption and Power-over-Ethernet
  • FIPS-197 compliant AES Encryption provides the ultimate in data protection at full line rate gigabit speeds with minimal latency
  • Carrier-grade 99.999% availability

Up to 3Gbps in 750MHz bandwidth per radio

APPLICATIONS

  • Business and residential broadband
  • Fiber extension/backup
  • HD video surveillance
  • Mobile and Wi-Fi backhaul



Flex4G-LITE delivers up to 3Gbps full-duplex data throughput per radio. Its high capacity and availability, coupled with its long range, make it the ideal system for wireless interconnects. Lightweight and compact, the Flex4G-LITE features a single optical interface carrying 2.5 Gbps of capacity, greatly simplifying deployment and minimizing the installation and connectivity costs typically incurred with legacy systems requiring multiple fiber runs.

With carrier networking features including CPRI protocol, the FL4G-LITE all-outdoor radio is the clear choice for carriers and ISPs seeking to quickly scale deployments and increase subscriber revenue.

FEATURES

  • All outdoor native Ethernet radio
  • Highest system gain full-duplex 3Gbps radio
  • 750/500/250MHz bandwidh
  • QPSK-64QAM with ACM and ATPC to maximize range
  • Six GigE Interfaces; one CPRI Interface
  • Ultra compact and lightweight
  • Integrated (ETSI) or external antennas (ANSI/ETSI)
  • Carrier-grade Layer 2 embedded Ethernet Switch
  • Carrier Grade network management
  • PoE and Direct DC Input

Longest range and highest availability of any 1Gbps 80GHz system

APPLICATIONS

  • Broadband/IP & Campus connectivity
  • Monitoring and control
  • Last-mile fiber extension
  • LAN extensions
  • Temporary links for disaster recover

Flex4G-1000 is an ultra-low cost 70/80GHz millimeter wave system delivering 1Gbps full-duplex data throughput per radio and the highest system gain of any 80GHz radio on the market. Available in both ANSI and ETSI versions, the Flex4G-1000 is ideal for wireless internet service providers (ISPs) and others seeking gigabit connectivity with carrier-class features and ease of installation at industry-leading price points.

Lightweight and ultra-compact to minimize installation and connectivity costs, the Flex4G-1000 features carrier-grade Ethernet switch functionality, hitless adaptive rate modulation, and ultra-low power consumption with support for both POE and direct DC power feed.

FEATURES

  • Highest availability & reach
  • Highest system gain
  • Full-duplex providing up to 1Gbps upstream & downstream
  • 1+0 and 2+0 configurations
  • Spectrum efficiency using 64QAM in 250, 500, and 750MHz wide channels
  • Hitless adaptive rate and modulation
  • QPSK/8PSK/16/32/64QAM modulation support
  • Internal carrier grade L2 switch
  • SyncE and IEEE1588v2 compliant
  • Power over Ethernet and Direct DC
  • Extreme ranges supported with optional 30cm (43.8dBi), 60cm (51dBi), and 90cm (54dBi) external slip-fit antennas
